Products Description
Industrial Oil Mist Filter is an environmental protection device developed for high - pollution scenarios such as metal processing and machinery manufacturing. It adopts a multi - stage composite purification technology (e.g., cyclonic separation, gradient filtration, and electrostatic adsorption), which can efficiently capture oil mist particles sized from 0.01 to 10 μm with a filtration efficiency of over 99.8%. The device realizes filter maintenance - free through an intelligent back - blowing system, reducing the annual operating cost by 40%. Its core advantages include an energy - saving design and modular adaptation with a flow rate range of 300 - 5000 m³/h available.
Product Principle
Centrifugal
Centrifuge high speed rotation separation.
Efficiency：≥2μm@＞99.5%
Regular cleaning is required.
Mechanical
Multi-level physical filtration.
Efficiency：≥0.3μm@＞99.5%
The filter element needs regular replacement.
Electrostatic
Electrostatic adsorption.
Efficiency：＜0.1μm@＞99%
Regular cleaning is required.
Product Parameters
| Model | SY-500 | SY-900 | SY-1500 |
| Voltage | 3Phasse 220V/380V HZ | ||
| Air Flow (m³/h) | 300-500 | 600-900 | 1100-1500 |
| Power(Kw) | 0.37 | 0.75 | 1.5 |
| Noise(dB) | 60 | 62 | 65 |
| Suction caliber (mm) | 120 | 150 | 180 |
| Noise (dB) | 60 | 62 | 65 |
| Efficiency | 99.8% | ||
| Four-stage filtration |
|
||
(Note: This is a reference for mechanical models.)
Application
- Mechanical processing
- Electronics manufacturing
- Aerospace
- Automobile manufacturing
- Food and pharmaceutical industries
Daily Maintenance
- Maintenance of the Filter Device: The filter device is the core component of the collector and requires special attention. In a typical machining workshop with moderate oil mist concentration, the filter element should be inspected every 1 - 2 weeks.
- Inspection of the Fan System: The fan is responsible for providing the suction force to collect the oil mist. Every day before starting the equipment, listen carefully to check if the fan is running smoothly and if there are any abnormal noises to ensure its normal operation.
- Inspection of Wire Insulation: Inspect the insulation condition of the wires quarterly. When the insulation resistance of the wires is lower than the specified value (generally 0.5 MΩ), there is a risk of electric leakage.
- Fault Handling: When a fault occurs in the equipment, it should be shut down immediately and the fault should be addressed promptly.
Customer Site
