Product Introduction
The hydraulic oil filtration cart is a mobile filtration unit designed to remove solid particles, water and dissolved contaminants from hydraulic oil. Benefits include:
- Remove 99.9% of Particles ≥ 3μm (β₃≥1000)
- Target Water Reduction to < 100 ppm (Optional Coalescer)
- Protect Pumps, Valves & Actuators from Costly Wear
- Extend Hydraulic Oil Life by 2-5X
- Quick-Connect: Filter In Minutes, Not Hours
Technical Parameters
| Feature | Specification (Model: SYH-A25) | Why It Matters |
| Flow Rate | 25 L/min | Fast cleaning for large reservoirs |
| Filtration Rating | β₃ ≥ 1000 (99.9% @ 3µm) | Targets the most damaging fine particles |
| Primary Filter Media | High-Grade Cellulose/Polyester Composite | High dirt holding capacity, cost-effective |
| Optional Water Removal | Coalescer: Reduces to < 100 ppm free water | Prevents hydrolysis & corrosion |
| Max Operating Pressure | 150 PSI (10 Bar) | Safe for most industrial systems |
| Motor Power | 0.55w AV 380V three-phase Motor | Reliable continuous duty |
| Ports | 1" NPT Quick-Connect (BSPP optional) | Fast, leak-free connections |
| Wheels | Heavy-Duty Pneumatic (Solid option) | Maneuverability on rough floors |
| Dimensions (LxBxH) | 430x350x950mm | Fits through standard doorways |
| Weight (Dry) | 35 kg | Stable operation, easy moving |
Key Features
✅ Modular Filter Cartridges:
Quick-swap design allows changing coarse/fine cartridges without tools.
Optional specialty cartridges for varnish removal or acid neutralization.
✅ Robust Construction:
Powder-coated steel frame with forklift slots and 4" non-marking caster wheels.
Marine-grade paint and stainless steel fittings for corrosion resistance.
✅ User-Friendly Controls:
Intuitive touchscreen interface: start/stop pump, view filter life, monitor oil temperature, water ppm.
Emergency stop button and over-pressure relief valve for operator safety.
✅ Low Maintenance:
Replaceable filter elements cost-effective; maintenance interval up to 1,000 operating hours or when differential pressure reaches 0.35 MPa.
Self-priming pump eliminates manual bleeding; automatic bypass protects in case of clogged filters.
✅ Optional Accessories:
Integrated thermometer, pressure gauges, and flow meter.
Spare parts kit: filter elements, O-rings, pump seals.
Applications
More Products
FAQ
Q: Can I use it while the hydraulic oil filtration cart is running?
A: Yes! That's the primary advantage. Connect to a low-pressure port or reservoir. Avoid high-pressure lines. Our carts are designed for safe online/offline use.
Q: How do I know when to change the filter element?
A: Monitor the differential pressure gauge. A significant pressure rise (e.g., 15-20 PSI over clean state) indicates saturation. Regular oil analysis also guides changes.
Q: Does it remove dissolved water or only free water?
A: Coalescers primarily remove free and emulsified water. For significant dissolved water, a vacuum dehydration unit is needed. Ask us about options.
