Products Description
The G78B3-1N resin bonded filter is a high-performance 5-micron depth filter cartridge constructed from a cellulose matrix and phenolic resin. Its groove structure design reliably removes particles even under demanding operating conditions, offering excellent value for money.
Product Details
 |
 |
 |
 |
Technical parameters
| Model | G78B3-1N |
| Filter Media | Cellulose + Phenolic |
| Retention Rating | 5 microns |
| Length | 9.75" (248 mm) |
| Outside Diameter | 1 1/16" (65.9 mm) |
| Inside Diameter | 2 19/32" (26.9 mm) |
| Max Operating Temperature | 121°C |
| Pressure Limits | 4.8 bar maximum differential, 2.4 bar recommended change point |
| Surface Configuration | Grooved design |
Key features
✅ Cellulose fiber blend ensures consistent 5-micron retention
✅ Phenolic resin binder creates durable, rigid structure
✅ Resin-bonded construction prevents fiber shedding
✅ No media migration ensures consistent effluent quality
✅ Compatible with standard industrial filter housings
Performance
G78B3-1N resin bonded filter retention efficiency:
Applications
- Paints, printing inks and coatings
- Adhesives and resins
- Solvent-based process streams
- Lubricants, coolants and hydraulic oils
- General industrial process water
- General chemical processing
Similar Models
|
G78B3-1P |
G78B3-1S | G78B3-1T |
| G78B3-2X | G78B3-2G | G78B3-2N |
| G78B3-3N | G78B3-3G | G78B3-3T |
| G78B3-4X | G78B3-4G | G78B3-4N |
| This page shows some of the models. We offer all models in the Micro-Klean RB Series. For customization, please contact us. | ||
workshop
 |
 |
 |
certificate
CE
Credit Certificates
ISO 9001
ISO 14001
FAQ
Q: Can it handle typical industrial chemical exposure?
A: Yes, the phenolic resin construction provides good resistance to common industrial chemicals and process fluids.
Q: What's the expected service life?
A: Service life depends on operating conditions, but the robust construction typically provides longer service than comparable meltblown or wound filters.
Q: Is special handling required during installation?
A: No, standard filter handling procedures apply. Ensure proper seating in compatible filter housings.
