Products Description
Our 5 Micron Resin Bonded Cartridge Filter redefines reliability in high-viscosity and high-particulate industrial filtration. Engineered with a proprietary dual-stage design, it eliminates premature clogging and bypass risks→delivering unmatched efficiency in chemical, petrochemical, and heavy-fluid applications.
Technical parameters
| Parameter | Specification |
| Filtration Media | Phenolic Resin-Bonded Acrylic & Polyester |
| Micron Rating | 5 µm |
| Outer Diameter | 65 mm (±1 mm) |
| Inner Diameter | 28 mm |
| Standard Lengths | 254 mm, 508 mm, 762 mm, 1016 mm |
| Max Operating Temperature | 121°C (250°F) |
| Max Differential Pressure | 4.8 bar (70 psid) |
| Recommended ΔP Change-Out | 2.4 bar (35 psid) |
| Seal Types | Double Open End (DOE), Single Open End (SOE-222/226) |
Product Types
 |
 |
 |
|
Acrylic Fiber With Phenolic Resin-bonded (Brown) |
Cellulose Fiber With Melamine Resin-bonded (White) |
Polyester Fiber With Phenolic Resin-bonded (Dark Brown) |
Key Advantages
✅ High-Precision Filtration: Ensures 99.9% retention efficiency for 5-micron particles.
✅ Chemical Compatibility: Resistant to acids and alkalis across pH range 2-12, suitable for diverse chemical media.
✅ High-Temperature Tolerance: Continuous operating temperature up to 121°C (250°F), with short-term resistance to 150°C (300°F).
✅ Structural Integrity: Burst pressure ≥0.8MPa (10.6 bar), ensuring safety and reliability under high-pressure conditions.
✅ Easy Installation & Maintenance: Standard interface design supports rapid replacement.
applications
- Paints & Inks with heavy pigments
- Resins & Adhesives with high viscosity
- Chemical Solvents at elevated temperatures
- Industrial Lubricants and process fluids
workshop
 |
 |
 |
Why choose us?
✅ No Media Migration: Ideal for protecting sensitive downstream equipment like membranes and chromatography columns.
✅ High Efficiency: Beta ratio ≥1000 at 5 µm ensures consistent and reliable filtration performance.
✅ Long Service Intervals: High dirt loading reduces operating costs and downtime.
✅ Customizable: Available in multiple lengths, end types, and seal materials (Silicone, EPDM, Viton).
certificate
CE
Credit Certificates
ISO 9001
ISO 14001
FAQ
Q: Are these cartridges good for high-viscosity fluids like resins or paints?
A: Yes. Their rigid, one-piece construction is specifically designed to handle the high pressures of viscous fluids without collapsing, unlike wound cartridges that can compress and fail.
Q: Is fiber shedding or media migration a problem?
A: No. Our cartridges are made without glues or binders. The fibers are permanently fused into a solid matrix through a high-pressure resin process, guaranteeing zero fiber shedding into your product.
Q: Can I get custom sizes or configurations?
A: Yes. We offer custom lengths, end-cap styles, and seal materials (like Viton or EPDM) to fit unique housing requirements. Contact us to discuss your needs.
