Products Description

SS bag filter housings are designed for liquid purification, particle interception and process fluid protection. The main body is made of high quality stainless steel (e.g. 304/316L), which combines excellent corrosion resistance, high strength and hygienic performance, and is suitable for use in harsh environments such as food and beverage, pharmaceutical, chemical, water treatment and electroplating.

Technical parameters

products
Model	SYCF-DS1-2#	SYCF-DS4-2#	SYCF-DS5-2#	SYCF-DS10-2#	SYCF-DS12-2#	SYCF-DS16-2#
Number of Bags	1	4	5	10	12	16
Maximum Flow Rate	20-40m³/h	80-100m³/h	100-120m³/h	200-220m³/h	240-260m³/h	320-340m³/h
Work Pressure	0.5MPa	0.5MPa	0.5MPa	0.5MPa	0.5MPa	0.5MPa
Material	304/316L SS	304/316L SS	304/316L SS	304/316L SS	304/316L SS	304/316L SS
Import and export	Φ63mm	dN100-DN150	dN100-DN150	dN200-DN250	dN200-DN250	dN200-DN250
Height	1050mm	1250mm	1286mm	1600mm	1600mm	1730mm
Diameter	219mm	500mm	550mm	800mm	800mm	950mm

*Only some of the model parameters are listed, if you need to refer to other model parameters, please contact us to obtain them for free.

Product Details

support basket

Customizable materials, thickness, and pore size to match your filtration needs.

Filter bags

Micron-level precision (0.5–1000µm) with replaceable designs for easy maintenance.

Quick-Open Eyebolts

Secure, leak-proof sealing for fast bag replacement.

Welding process

Professional welding technology, strong stability and beauty.

features

High Flow Rates

From 20m³/H to 340m³/H – scalable for small to large operations.

Adjustable Legs

Adapt to uneven surfaces or confined spaces.

Corrosion-Resistant

Built to last in aggressive chemical or high-viscosity applications.

Low Maintenance

Easy-access design and standardized components reduce downtime.

Applications

01/

Mining & Metallurgy
Slurry Filtration: Handle high-solid slurries in mineral processing without clogging. 316L steel resists acidic leaching solutions.

02/

Pulp & Paper
Black Liquor Filtration: Remove particulates from corrosive byproducts during paper bleaching.

03/

Wastewater Treatment
Filter industrial effluents (chemicals, oils, heavy metals) to meet discharge regulations.
Capture sludge particles in activated sludge processes.

04/

Power Generation
Boiler Feed Water: Prevent scale and sediment buildup in turbines and boilers.
Cooling Towers: Catch algae, rust, and debris to avoid clogged heat exchangers.

05/

Automotive & Aerospace
Paint Lines: Trap overspray residues in coating systems to maintain spray booth efficiency.
Coolant Systems: Filter metal shavings and grinding debris from machining coolants, extending fluid lifespan.

06/

Oil & Gas
Drilling Fluids: Filter abrasive particles from muds to protect pumps and valves.
Fuel Polishing: Remove contaminants from diesel or lubricants to keep generators and machinery running cleanly.
