Product Overview
The DN200 Cartridge Filter Housing SYB-4-100X is a multi-cartridge vessel configured for a rated flow of 195 t/h. It uses a DN200 process connection and provides space for 131 pieces of 40-inch filter cartridges within a housing measuring approximately Φ1000 × 2150 mm.
The vessel is constructed with a 5 mm wall thickness and uses a flange and support-arm arrangement. Available housing materials include carbon steel, stainless steel 304, and stainless steel 316, allowing the vessel specification to be matched to the liquid medium and operating environment.
Engineering Data
| Engineering Parameter | SYB-4-100X |
|---|---|
| Product Type | Multi-Cartridge Filter Housing |
| Nominal Connection | DN200 |
| Vessel Dimensions | Φ1000 × 2150 mm |
| Wall Thickness | 5 mm |
| Cartridge Capacity | 131 pcs |
| Cartridge Length | 40 inch |
| Rated Flow | 195 t/h |
| Closure / Support Structure | Flange + Support Arm |
| Housing Materials | Carbon Steel / SS304 / SS316 |
Configuration Details
DN200 Process Interface
The DN200 connection is the defined process interface for this configuration. It should be checked against the existing pipeline size and connection arrangement during system integration.
131-Cartridge Arrangement
The vessel accommodates 131 filter cartridges, with each cartridge specified at 40 inches in length. This arrangement allows numerous individual elements to be installed within a single filtration vessel.
195 t/h Rated Flow
The listed rated flow is 195 t/h. Actual filtration throughput should be assessed together with cartridge media, filtration rating, liquid viscosity, contaminant concentration, and allowable pressure drop.
5 mm Housing Wall
The housing specification lists a 5 mm wall thickness for the SYB-4-100X. This dimensional parameter should be considered together with the required operating pressure and applicable equipment design conditions.
CE
ISO 14001
ISO 9001
SGS
Where Can It Be Installed?
Based on the supplied configuration, this Cartridge Filter Housing can be evaluated for the following liquid filtration positions:
- Process liquid filtration: installed in a process line where liquid passes through multiple cartridge elements.
- Water filtration: used as a cartridge-based filtration stage when the selected cartridges match the water quality and filtration requirement.
- Upstream particle removal: positioned before downstream treatment or process equipment where particulate control is required.
- Continuous-flow systems: used where a larger number of cartridges operate together within one vessel.
The actual application should be confirmed from the process medium, cartridge specification, design flow, operating pressure, temperature, and required filtration level.
