Products Description
The water bag filter housing is an industrial-grade filtration device. Constructed of 304 stainless steel, it accommodates filter bags or stainless steel filter baskets to meet varying filter accuracy and capacity requirements. The housing features 1-inch NPT inlet and outlet ports to ensure smooth liquid flow and is compatible with conventional pipe connections.
Technical Details
| Part Number | L025017FBA |
| Size | 1.2 SQ FT |
| Package Dimensions | 66.04 x 31.19 x 31.19 cm; 10.02 kg |
| Material | 304 stainless steel |
| Filter Area | 1.2 ft² |
| O-ring | EDPM |
| Filtering Accuracy | 20μm |
| Maximum Working Pressure | 120 psi |
| Operating Temperature | -20°C ~ 120°C |
| Bag Size Compatibility | #1 (Ø180×430mm), #2 (Ø180×810mm), #3/#4 compact bags |
| Manufacturer | Ayater |
video
Features & Benefits
✅The water bag filter housing accommodates a variety of filtration methods.
✅It accommodates filter bags or stainless steel filter baskets.
✅304 stainless steel construction provides corrosion resistance and high strength.
✅Reliable sealing design enhances liquid purity and equipment safety.
✅1-inch NPT inlet and outlet ports allow for standardized installation.
✅The quick-open lid reduces downtime.
✅Optimized flow path, low resistance, and high energy efficiency.
✅Filter bag material, filter accuracy, and multi-bag configurations can be customized to meet customer needs.
Customer Cases
Application field
👉Water Treatment
👉Paints & Coatings
👉Food & Beverage
👉Pharmaceuticals & Cosmetics
👉Chemical Industry
👉Electronics Industry
High-end inkjet printing platemaking factory (EU region)
- Challenge: Approximately 50 m³ of industrial water is processed daily. The original system used microporous membrane filtration, which was prone to scaling and frequent clogging, resulting in short cleaning cycles and long downtime.
- Solution: The L025017FBA Water Bag Filter Housing, made of 304 stainless steel, comes standard with 20 μm #4 filter bags and a real-time pressure gauge. Two units are connected in series to automatically recover filtered liquid and treat secondary water.
- Implementation results: Replacement cycles have been extended from approximately 3–4 days to 14–21 days. Downtime has been reduced from approximately 8 hours per month for cleaning and replacement to only approximately 2 hours per month for filter bag replacement, resulting in safer and more efficient production. Filter bag costs have been reduced by approximately 40%, and overall operating and maintenance expenses have been reduced by 35%.
Factory real shots
|
|
|
|
|
|
